| Specifications | |
| Dimensions (W x H x D) | 300 x 70 x 212 mm 6.30 x 0.98 x 3.70 inch |
| Volume | 4.46L |
| Weight | 3.2 kgs / 7.1 lbs |
| CPU | 11th Generation Intel® Core™ (i3, i5, i7, i9) |
| GPU | Intel® UHD 610 / 630 |
| Chipset | - |
| AiCU | - |
| Memory | Dual Channel DDR4 SO-DIMM 2400 / 2666 MHz 32GB |
| Expansion | M.2 2280 x 1 M.2 2242 / 2280 x 1, M.2 2230 x 1 |
| LAN | Intel Gigabit i219 x 1 10 / 100 / 1000 Mbps |
| Storage | M.2 SSD x 2 |
| Front Panel I/O | USB3.2 x 2 Line-out x 1 Mic-in x 1 USBC x 1 |
| Rear Panel I/O | DC Jack x 1 HDMI1.4 x 1 DP1.4 x 1 USB3.2 x 4 RJ45 LAN x 1 Antenna Holes x 2 Discrete Graphics Card Slot x 1 |
| CPU Thermal Module | AOPEN Thermal Module |
| WatchDog Timer | 1 ~ 255 SEC./ min |
| Adapter | AC 100 ~ 240V |
| Input Voltage | 180W / 19.5V / 9.23A |
| Warranty | 2 Years |
| MTBF | 50.000 hrs |
| Operating Temperature | 0 ~ 45° C (32 ~ 113° F) |
| Storage Temperature | 0 ~ 60° C (-4 ~ 140° F) |
| Relative Humidity | 95% RH (45° non-condensing) |
