Finished housing
1920×1080 Resolution
350nit Brightness
Optional Wi-Fi
Built in SoC Options. Included HDMI™ connectivity
Finished housing
1920×1080 Resolution
350nit Brightness
Optional Wi-Fi
Built in SoC Options. Included HDMI™ connectivity
| Specifications | |
| DISPLAY | |
| 49.0'' LCD Screen | Viewing Angle: 89/89/89/89 |
| Resolution: 1920x1080 | Contrast: 1200CR |
| Max Brightness: 500 nits | |
| SYSTEM | |
| Included HDMI™ connectivity | |
| Built in SoC Options: | |
| BrightSign HS145 | |
| Bluefin Intel Ocean | |
| Rockchip RK3399 | |
| POWER | |
| Adapter Style: Mini Molex | Adapter Output: 24V 6A |
| Adapter SKU: 20-0150-0750 | |
| INPUT / OUTPUT | |
| HDMI™-In | RJ45 Ethernet |
| 1x Micro-SD | 3.5mm Analog/Digital Audio Out |
| 1x USB 2.0 | Optional Wi-Fi |
| Phoenix GPIO (4-pin Bi-Directional) | |
| 3.5mm RS232 Serial | |
| * Phoenix GPIO only supported with BrightSign. Only HDMI™ port available when no player is installed. | |
| HOUSING / MOUNTING | |
| Finished Non-Touch | |
| Size: 42.9 x 24.5 x 2.1’’ | |
| Weight: 17.5kg | |
| Mounting: VESA 400x300mm M8x10mm | |
