LG 1300nits Outdoor Signage 22XE1J

Key Features

Brightness (Typ, w/ Glass) : 1,500 nits
IP56 Rated Dust / Water Proof
21.5″ of Versatile Display Size
Wide Operating Temperature Range
webOS Smart Platform
Web-based Monitoring Solution

Versatile Outdoor Display Fit for Your Business

High Visibility Under Bright Environments

With a brightness of 1,500 nits, 22XE1J boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.

21.5 inches of Versatile Screen Size

The small and light size of 21.5 inches allows for flexible use in various spaces. In particular, you can install the display in various way allowing for high utilization for small-medium businesses (SMB) to large businesses.

Secured Protection with IP56 Design

The display is sealed with IP56 design for reliable operation. It’s designed to be not only waterproof but also weatherproof against the damaging effects of the sun, rain, snow, dust and wind, which is an essential feature for outdoor application.

Wide Operating Temperature Range

22XE1J can be used under a wide range of operating temperatures which results in fewer constraints for outdoor installation.

Conformal Coating

Conformal Coating* improves reliability of the circuit board, power board by protecting it against dust, iron powder, humidity, etc.

Smart Brightness Control

The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.

Easy Content Distribution & SW Update

22XE1J features embedded Wi-Fi*, Bluetooth, Beacon making it easy to distribute content wirelessly and update Firmware. In particular, using Beacon and BLE (Bluetooth Low Energy), shop manager can do various promotional activities, such as providing promotional coupons or product information to visitor in real time.

High Performance with webOS

Quad Core SoC* can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.

Brightness (Typ, w/ Glass) : 1,500 nits
IP56 Rated Dust / Water Proof
21.5″ of Versatile Display Size
Wide Operating Temperature Range
webOS Smart Platform
Web-based Monitoring Solution

LG 22XE1J-B

Panel
Screen Size	21.5"
Panel Technology	AHVA (IPS)
Back Light Type	Edge
Aspect Ratio	16:9
Native Resolution	1,920 x 1,080 (FHD)
Refresh Rate	60Hz
Brightness	1,500nit (Typ, w/ Glass)
Contrast Ratio	1,000:1 (Typ)
Dynamic CR	800,000:1
Color gamut	NTSC 72%
Viewing Angle (H x V)	178 x 178
Color Depth	8bit, 16.7Million colors
Response Time	25ms (G to G)
Surface Treatment (Haze)	Anti glare, 3H (Haze 25%)
Lifetime	50,000 Hrs (Min.)
Operation Hours (Hours / Days)	24/7
Portrait / Landscape	Yes / Yes
QWP (Quarter Wave Plate)	Yes (Apply on glass)
Mechanical Specification
Bezel Color	Black
Bezel Width	38.3mm (R/L), 24.0mm (T/B)
Weight (Head)	8.7 kg
Packed Weight	10kg
Monitor Dimensions (W × H × D)	557.3 x 319.8 x 66 mm
Carton Dimensions (W × H × D)	632 x 394 x 187 mm (Box outer size)
VESA™ Standard Mount Interface	100x100
Protection Glass	Depth 3mm, Tempered / Chemical strengthening (Chemical strengthening), Anti-Reflective, Infrared - Resistance (IR), Shatter-Proof
Key Feature
HW	Internal Memory 16GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness sensor, Humidity Sensor, Acceleration (Gyro) Sensor, Power Indicator, FAN
SW	webOS ver. (webOS4.1), Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (Local Network Sync), Video Tag (4, Max One HDMI input), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), Beacon, HDMI-CEC, SI Server Setting , webRTC, Pro:Idiom
Environment Conditions
Operation Temperature	-30°C to 50 °C
Operation Humidity	5 % to 100 %
Power
Power Supply	AC 100-240V~, 50/60Hz
Power Type	Built-In Power
Power Consumption
Typ.	85W (Full White) 36W (IEC 62087)
Max.	115W
DPM	0.5W↓
Power off	0.5W↓
BTU (British Thermal Unit)	290 (Typ), 393 (Max)
Certification
Safety	CB / NRTL
EMC	FCC Class "A" / CE / KC / VCCI
ErP	Yes
Software Compatibility
SuperSign CMS	Yes
SuperSign Control / Control+	Yes / Yes
LG ConnectedCare	Yes
Connectivity
Input	HDMI (HDCP 2.2), RS232C IN, RJ45 (LAN), USB2.0 Type A (1)
Output	Externel Speaker Out (1, L/R, 10W+10W)
Language
OSD	English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arab, Türkiye
Accessory
Basic	Remote Controller (including battery 2ea), Power Cord, Manual (EIG, IG), RS-232C Gender
Special Feature
Tilt (Facedown)	Yes (Max -15º degree, Face Down) PP
IP Rating	IP56
Direct Sunlight	Yes
