| Specifications | ||||
| Panel | ||||
| Screen Size (Inch) | 110" ,98" | Panel Technology | ADS | |
| Back Light Type | Direct | Aspect Ratio | 16:9 | |
| Native Resolution | 3840 x 2160 (UHD) | Refresh Rate | 120Hz | |
| Brightness (Typ.) | 500nit (Typ.) | Contrast Ratio | 1,200:1 | |
| Dynamic CR | 1,000,000:1 | Color Gamut | DCI-P3 88%↑ | |
| Viewing Angle (H x V) | 178 x 178 | Color Depth | 8bit + FRC, 1.07Billion colors | |
| Response Time | 8m (G to G) | Surface Treatment(Haze) | 1% | |
| Life time | 50,000Hrs (Min.) | Operation Hours (Hours/Day) | 16/7 | |
| Portrait / Landscape | No / Yes | |||
| Connectivity (Jack Interface) | ||||
| HDMI IN | O(3) HDMI1/HDMI2 : HDCP 2.2/1.4 HDMI3 : HDCP 1.4 | DP IN | Yes (1), HDCP2.2/1.3 | |
| DVI-D IN | Yes (1), HDCP1.4 | Audio IN | Yes (1) | |
| RS232C IN | Yes (1), 4pin Phone-jack | RJ45(LAN) IN | Yes (1) | |
| IR IN | Yes (1) | USB IN | USB2.0 Type A(1) | |
| HDMI Out | Yes (1) | Audio Out | Yes (1) | |
| RS232C Out | Yes (1), 4pin Phone-jack | Daisy Chain | Yes (Input HDMI, DP, DVI / Output HDMI) | |
| Mechanical | ||||
| Bezel Color | Black | Bezel Width | Even bezel: 17mm | |
| Weight (Head) | - | Packed Weight | ||
| Monitor Dimensions (W x H x D) | - | Carton Dimensions (W x H x D) | - | |
| Handle | Yes | VESA™ Standard Mount Interface | 1500 x 600 | |
| HW Feature | ||||
| Internal Memory | 16GB | Wi-Fi (Built-in) | Yes | |
| Temperature Sensor | Yes | Auto Brightness sensor | Yes | |
| Acceleration(Gyro) Sensor | Yes | Power Indicator | Yes | |
| Local Key Operation | Yes | Speaker (Built-in) | Yes (10W X 2) | |
| SW Feature | ||||
| OS ver. | webOS6.0 | Local Contents Scheduling | Yes | |
| Group Manager | Yes | USB Plug & Play | Yes | |
| Fail over | Yes | Booting Logo Image | Yes | |
| No Signal Image | Yes | RS232C Sync | Yes | |
| Local Network Sync | Yes | PIP | Yes | |
| PBP | Yes (4) | Screen Share | Yes | |
| Video Tag | Yes (4) | Play via URL | Yes | |
| Screen Rotation | No | External Input Rotation | No | |
| Gapless Playback | Yes | Tile Mode Setting | Yes (Max. 15x15) | |
| Setting Data Cloning | Yes | SNMP | Yes | |
| ISM Method | Yes | Auto Set ID | Yes | |
| Status Mailing | Yes | Control Manager | Yes | |
| Cisco Certi. | Yes | Crestron Connected | Yes | |
| Smart Energy Saving | Yes | PM mode | Yes | |
| Wake on LAN | Yes | Network Ready | Yes | |
| Beacon | Yes | HDMI-CEC | Yes | |
| SI Server Setting | Yes | webRTC | Yes | |
| Pro:Idiom | Yes | |||
| Environment Conditions | ||||
| Operation Temperature | 0°C to 40°C | Operation Humidity | 10 % to 80 % | |
| Power | ||||
| Power Supply | AC 100-240V~, 50/60Hz | Power Type | Built-In Power | |
| Power Consumption | ||||
| Power Consumption (Typ.) | 440W | Power Consumption (Max.) | 570W | |
| Power Consumption (British Thermal Unit) | 1501 BTU/Hr(Typ.), 1945 BTU/Hr(Max) | Power Consumption (Smart Energy Saving, ~70%) | 308W | |
| Power Consumption (DPM) | 0.5W | Power Consumption (Power Off) | 0.5W | |
| Certification | ||||
| Safety | CB / NRTL | EMC | FCC Class "A" / CE / KC | |
| ErP / Energy Star | Yes (NewErP) / No | |||
| Software Compatibility | ||||
| SuperSign CMS | Yes | SuperSign Control+ | Yes | |
| SuperSign WB | Yes | SuperSign Cloud | Yes | |
| Mobile CMS | Yes | Connected Care | Yes | |
